TIUH60 MPU-24

Specifically designed to fit the UH-60 Black Hawk Helicopter.
Ideal for testing and troubleshooting avionics, and weapons systems.
Complete battery system that incorporates patented power cell technology with an intelligent charging system and ac-dc converter.
Provides faster, cooler aircraft starts while eliminating the problems normally associated with aviation batteries and battery maintenance.
Built in Capacity Meter/Recharge State Indicator.
Maintenance-free design.
Non-hazardous, dry-cell technology.
5 to 7 year battery service life.
Back-charges off of dc aircraft bus.
Plugs into ac power to recharge cells.
Non-hazardous, dry-cell technology.
Back-charges off of dc aircraft bus.

TIUH60 MPU-24 Specifications

DC Output:	750 peak starting amps 10 amps continuous @ 28.5 Vdc (when plugged into ac power) 21.5 amp hours (541 watt hours) with ac power 11.5 amp hours (256 watt hours) of rechargeable battery power without ac
AC Input:	Operates and charges from Single Phase 100-260 Vac 45-450 Hz 5.5 amps @ single phase 120 Vac 2.75 amps @ single phase 240 Vac
Recharging Rate:	74 minutes (from full discharge) @ 25°C
Dimensions:	8.45" L x 9.88" W x 7.57" H 214.7 mm x 250.8 mm x 192.2 mm
Weight:	27 lbs (12.25 kg)
Warranty:	3 Years
